Shinybow SB-1102G 1x2 VGA Amplifier Splitter


Description :

The 1x2 VGA Distribution Amplifier, SB-1102G is designed to work as a splitter for VGA Video applications. Capable of splitting a VGA signal from one source to two devices with compatible inputs. A built in video distribution amplifier will boost the signal to the needed level, to prevent signal loss and picture degradation. A maximum bandwidth of >1GHz will support a sharp and highly defined video in multiple resolutions of up to 2048 x 2048. The 1 x 2 VGA Distribution Amplifier works with all Video equipment that has proper connections such as Cable and Satellite receivers, and Computers.



Item Number: #SB_1102G
Price: $119.00
Sale Price: $69.12

Availability: instock

Quantity:

Product Features



  • 1 Input to 2 DA Outputs and 1 Preview Output VGA Distribution Amplifier
  • Signal Bandwidth >1GHz
  • Low Distortion over Wide Bandwidth
  • High resolution up to 2048x2048
  • High Output Drive 175 mA Output Load Drive
  • Scan rates accepted: 50Hz or 60Hz
  • Enclosure type: Support wall mountable
  • Size: (6.92")W x (3.15")D x (1")H inches


Specifications

Type of Amplifier
1 input To 2 outputs VGA Distribution Amplifier
I/O signals
RGBHV, RGBS, RGsB (RGB Level Range 0.5~2.0 Vp-p)
Video Bandwidth
Large signal 440MHz. small signal(-3dB) 1 GHz
Slew Rate
5500 V/as,4V Step, G=+2
Settling Time:
10 ns to 0.1%, 2 V Step, G=+2
Gain Flatness
1.0.1 dB to 75MHz, Rl=150% 2.0.01 differential gain error;
Rl=150% 3.0.01 differential phase error;Rl=1 50%
Low Distortion SFDR
1. -66 dBc @ 20 Mhz, Second Harmonic 2. -75 dBc @ 20MHz, Third Harmonic
High Resolution
Maximum 2048 x 2048
Amplifier Unit
FCC, CE, RoHS(2002/95/EC)
Power Supplies
UL, CE, CSA, TUV, BS
Power distortion
400 mA full load
Dimensions
(6.92")W x (3.15")D x (1")H inches
Power Voltage Input
DC 12V @300mA, ~3A accepted
