Shinybow SB-1116G 1x16 VGA Amplifier Splitter


Description :

1x16 VGA Amplifier Splitter, SB-1116 is an ultrahigh speed current feed back amplifier with an excellent 5500V/as slew rate that results in a rise time of 545ps, making it ideal as a pulse amplifier. The high slew rate lowers the effect of slew rate limiting and results in the large signal Bandwidth 440MHz(G=+2), Small signal Bandwidth (-3dB) 1000MHz(G=+1) delivers computer resolutions up to 2048 x 2048 at distances up to 1 50 feet away without signal deterioration. 1x16 VGA splitter maintains high signal quality over a wide bandwidth with worst-case distortion of-40dBc@250MHz (G=+10, 1 Vp-p). Input and output connectors are HD-15 female type. The SB-1116MRM is housed 19 inch rack mountable metal cases, 1 RU high. All units are +12VDC powered, which includes a power adapter.



Item Number: #SB-1116G
Price: $475.00
Sale Price: $253.44

Availability: instock

Quantity:

Product Features



  • 1 input to 16 outputs VGA Distribution Amplifier
  • Large Signal Bandwidth 440MHz, G=+2
  • Small signal Bandwidth(-3dB) 1GHz, G=+1
  • Settling Time 10 ns to 0.1%, 2 V Step, G=+2
  • Low Distortion over Wide Bandwidth
  • High resolution for VGA, SVGA, XGA, UXGA,WUXGA 1920x1200
  • High Output Drive 175 mA Output Load Drive
  • Scan rates accepted : 50Hz or 60Hz
  • Enclosure type : Support wall mountable
  • Support Lower power consumed full load under 500mA
  • Rack Mount bracket optional


Specifications

Type of Amplifier
1 input To 16 outputs VGA Distribution Amplifier
I/O signals
RGBHV, RGBS, RGsB (RGB Level Range 0.5~2.0 Vp-p)
Video Bandwidth
Large signal 440MHz, small signal(-3dB) 1 GHz
Slew Rate
5500 V/aS, 4V Step, G=+2
Settling Time
10 ns to 0.1%, 2 V Step, G=+2
Gain flatness
0.1 dB to 75MHz, Rl=150% 1. 0.01% differential gain error; Rl=150% 2. 0.01% differential phase error; Rl=150%
Low distortion SFDR
-66 dBc @ 20 Mhz, Second Harmonic 1. -75 dBc @ 20MHz, Third Harmonic
High Resolution
Maximum 2048 x 2048
Amplifier Unit
FCC, CE, RoHS(2002/95/EC)
Power Supplies
UL, CE, CSA, TUV, BS
Power distortion
400 mA full load
Dimensions (W.D.H.)
17.32" (W)x 7.80" (D)x 1.73" (H)
Power Voltage Input
DC 12V@500mA, -3Aaccepted
