Shinybow SB-1110 2x8 VGA Switch/Splitter (2-in/8-out)

( 53 Reviews )

#SB-1110

Please call us @ 216-798-7530 for Pricing and Availability

Description :

The 2x8 VGA Switch/Splitter (2-in/8-out) SB-1110 is a high speed Video Bandwidth 310MHz, Maximum 380 Mhz VGA distribution amplifier with 2 channel switcher. It is one of the most innovative 8 VGA-RGBHV distributor products with routing switcher function on the market Today.
SB-1110 supports 2 VGA Inputs and can be switched to 8 VGA distribution Outputs for high resolution VGA, SVGA, XGA, SXGA, UXGA, WUXGA. It has 2 individual inputs and with 8 outputs (all the same). Because it uses switching function into a video distribution amplifier, any input can be switched to the 8 same outputs. It completely eliminates the need to constantly move around VGA input and output cables. The SB-1110 is ideally suited for High Definition LCD Television or PC Plasma display applications. Control is provided via Front push buttons with LED readout or IR remote controller.

Description
Reviews (5)

Product Features

Support 2 inputs to 8 outputs VGA Distribution Amplifier
2 x 8 high speed non-blocking switch arrays
Front pushbuttons with LED readout
Switching RGBHV in LCD monitors and plasma VGA displays monitors
Suitable for XGA, SXGA, UXGA, WUXGA(1920x1200) resolution displays

Specifications

Input	2x VGA(RGBHV) DB-15F
Output	8x VGA(RGBHV) DB-15F
Video Bandwidth	380MHz (-3dB), 200mVp-p
Excellent ESD rating	Exceeds 4000V
Infrared	IR remote control (38KHz)
Enclosure type	All metal - Desktop.
Power Source:	DC+12V 500mA
Lower power consumption under full load under 450 mA
IR Remote Controller(38.5KHz)
Low all hostile crosstalk of -83 dB @ 5 Mhz
