ALPV154T 4 Way Line Powered VGA Extender to 150 meters USB Powered at Transmitter


$365.00 $328.50


Description :

The ALPV154T is able to take the same HD input and send it to 4 different screens connected via the ALPV150R receivers. There is a feed through port on the unit to allow a local display or you can cascade another ALAV154T so you can supply 8 screens.

To help reduce cable clutter, the ADDERLink LPV150 has been designed to be powered by a USB port on your computer. Furthermore, this power is also transmitted alongside the video over the CATx cable, in turn powering your receiver unit.




Product Features



Specifications

Video Resolutions
Maximum of 1920x1200@60Hz
Extension Distance
150 meters at 1920 x1080@60Hz
Max cable skew allowed
25ns over maximum cable length. Recommend low skew cables over 50 meters (see manual)
O/S Compatibility
Operating system independent
Connectors
USB Type A ,15 pin VGA and one RJ45 port. (ALPV150P) 2 x 15 pin VGA, 4 x RJ45, 1 x power, 1 x 4P4C RS232. (ALPV154T)
Power
LPV 150P USB powered (Max 500mA @5V)
LPV154T 5V @ 2.5A, power unit provided
Physical
Transmitter
High impact injection moulding 45mm (w), 63 mm (l), 21mm (d) - excluding cables
Receiver
High impact injection moulding 45mm (w), 63 mm (l), 21mm (d) - excluding cables
ALPV154T
Steel enclosure: 100mm (w), 100 mm (l), 25mm (d)
Operating temperature
0-40 deg C
Approvals
CE, FCC
Optional Accessories
ALPV150R: Adder line powered VGA Extender receiver unit;
ALAV-RMK-FASCIA: Rack mount fascia plate;
ALAV-RMK-CHASSIS: 19" rack mount chassis
