XT-TX400S CAT5 VGA/Audio/RS232/IR Splitter Extender over CAT5e/6 UTP Cable, 4 Ports

( 83 Reviews )

#XT-TX400S

$425.00 $330.00

Description :

The SmartAVI XT-TX400S CAT5 VGA/AUDIO/RS232/IR Splitter Extender range of products allows extension of a VGA Video/Audio formats and RS232 to four locations simultaneously using Cat5e/6 UTP Cables. This VGA over Cat5 Audio Splitter Extender has a local VGA/Audio port on the transmitter to connect a VGA Monitor and Audio right next to the PC.

RECEIVERS SOLD SEPARATELY (SEE BELOW)

Add to Cart

Product Features

Supports Dual screens
Uses Easy to install and inexpensive CAT5/5e/6/7/8
Each Output reaches up to 1000 feet
Supports High resolution video up to 1920x1200
HDTV Compatible (720p, 1080i,1080p)
300 MHz Bandwidth
Sends High-resolution VGA, Stereo Audio signals, RS232 or IR from one source to four locations
Compatible with VGA, XGA, Sun, MAC and SGI
Sync Format / Polarity Preservation
Compatible with Line Level Stereo Audio Signals
High ground loop immunity.
Built-in power surge and transient protection
Designated trimmer in the remote unit to compensate for cable length
Compact Metal Case Enclosure
External power supply
RS232 Communication support to single or multiple Displays
IR command to single or multiple Displays(Optional)

Specifications

VGA Data
Format	RGBHV, RGsB, YUV, Y/C, CVBS
Resolution	Up to 1900 x 1200 VGA, SVGA, XGA, SXGA
Connector type	HD 15 socket
Audio
Signal Type	Stereo Unbalanced
Connector	3.5mm Jack socket
RS232	DB9M, TXD, RXD, Gnd., 9600 bps
Mechanical
Dimensions	8.6 x 4.6 x 1.1* in. (22 x 11.8 x 2.7cm) (*1.2 in. / 3.1 cm.with pegs)
Weight( Shipping)	3 lbs
Power
Requirements	5VDC @.5A
Connector	2.1mm DC jack (center +ve)

View User Manual
