1U 17" Widescreen 1080p High Resolution 1920 x 1080 Rackmount LCD Monitor with HDMI and VGA Connectors


#RKMTL-1U-17-HDV
$2100.00 $1899.00


Description :

1U 17" WideScreen 1080p High Resolution 1920x1080 Rackmount LCD, RKMTL-1U-17-HDV also referred to as 1U LCD is a flip up Monitor in 1U Drawer. This Rack lcd unit saves space for your Rack environment. These LCDs support simple plug and play functionality and do not require any additional software. This RKMTL-1U-17-HDV, TFT Rackmount LCD Monitor allows for viewing and monitoring of data even through closed glass doors. 1U Rack Mount LCD monitor units come with an industrial grade LCD panel.

1U 17 Widescreen 1080p High Resolution 1920 x 1080 Rackmount LCD Monitor with HDMI, DVI-D and VGA Connectors




Product Features



  • 1U Rackmount 17" Widescreen LCD
  • 1920 x 1080 Native high resolution
  • Support full HD with 1080p resolution
  • Green LED-backlit panel technology
  • 1.07 Billion true colors, 10-bit
  • Built-in HDMI and VGA Connectors
  • 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • 17" Touchscreen : Capacitive, Resistive (Optional)
  • 48V, 24V or 12VDC input (Optional)
  • MIL-Type or lockable connector (Optional)

Specifications

LCD Panel
Size (diagonal)
17.3" TFT
Max resolution
1920 x 1080
Brightness (cd/m2)
400
Backlight
LED

Colors
16.7 Million, 8-bit
Contrast ratio (typ)
600 : 1
Viewing Angle (H/V)
160° x 140°
Active area (mm)
382 x 215
MTBF (hrs)
20,000
Signal input
HDMI  / VGA
Environmental
Operating
0 to 50°C Degree
Storage
-5 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G Acceleration ( 11 ms duration )
Vibration
5~500Hz 1G RMS Random Vibration
Casing Color
Black front panel ( RAL 9005 )
Dark grey rear case ( RAL 7037 )
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 48 Watt, standby 5 watt
Dimensions

Product
17.4 x 20.9 x 1.73 inches
Packing
 27 x 23.2 x 4.7 inches
Weight

Net
26 lbs
Certifications
CE, FCC, RoHS
