- HDBaseT™ TX/RX with 3D, 4K2K over a single UTP/STP cable up to 330ft (100M)
- Supports HDMI 1080p@60 video V1.4a 3D and Ultra HD 4K2K video, CEC / HDCP compliant
- Supports link speeds for TMDS Video formats up to a max 10.2Gbit/s, Signal 340MHz Deep Color, Full HD 1080p@60Hz@24/36/48bit/pixels
- Supports 1080p TV’s at 24/30/60/100/200/240Hz and above as well as Blu-rays at 24FPS
- Supports Digital Audio 7.1 LPCM 192KHz, 24bits, Full HD Dolby TrueHD and DTS-HD Master Audio uncompressed HD audio formats
- Supports PoH power DC48V over HDBaseT™ (Power supports 48VDC from SB-6335T5 Transmitter)
- Transfers Bi-directional Infrared control signal together with the HDMI signal
- RS-232 port for firmware updates or RS-232 control signal transmission
- Supports HDMI CEC between your connected source and display gear
- LED indicators show the HDCP/LINK/POWER/POE status
- HDBaseT™ transfers HDMI, PoE, LAN, RS-232 and Bi-Directional IR over single category cable
- Supports Super Audio CD (DSD), CEC commands protocol table
Specifications
|
Type of Extender
|
HDBaseT™ RX & TX use HDMI signal over category UTP/STP Cable
|
|
Input Signals
|
HDMI with Digital Video (TMDS)/Audio 0.5~1.0vPP, DDC 5Vpp
|
|
HDBaseT™ Signal Supports
|
HDMI 1.4a HDMI format Standard, DVI and HDCP Compliant
|
|
Video Support
|
HDMI and DVI TMDS format for 1920x1200 resolution up to 10.2Gbps (340MHz), Digital RGB 48bits/px, deep color, 3D
|
|
Category Cable Support
|
CAT5e, CAT6, CAT6a, CAT7 UTP/STP cable
|
|
Support HDMI Resolutions
|
480p, 720p, 1080i/1080p and Ultra HD 4K2K
|
|
Scan Rate Accepted
|
Support HDMI full HD Resolution; Frequency 24Hz to 240Hz
|
|
Controls
|
- 1x IR in
- 1x IR out
- 1x RS-232 I/O
- 1x LAN series interface Rx High input Impedance: 1 M? differential
|
|
PoH Support
|
HDBaseT™ Receiver support 48VDC power from Transmitter (SB-6351T)
|
|
Transfer Distance
|
Up to 330ft (100M)
|
|
Low Distortion
|
- Tx: 68dB SFDR@5Mhz 200? load
- Rx: 1Vpp@5MHz
|
|
HDMI I/O Connectors
|
HDMI Type A-SMD 19pin Female Type
|
|
HDBaseT™ I/O Connectors
|
HDBaseT™ RJ-45, 8p8c Female socket
|
|
Temperature
|
32°F-122°F Operation (0°C~50°C)
|
|
Safety Approvals
|
CE, FCC, VCCI, REACH
|
|
Size(LxWxH)
|
4.33 x 4.73 x 1.38 in (110x120x35 mm)
|
|
Shipping Weight (net)
|
0.36 kg/0.80 lb
|
|
Power Consumption
|
Max 1000mA (Full load 1080p-60Hz signal with use DC48V input)
|
|
