Shinybow Part #: SB-6335T In stock

Shinybow SB-6335T HDMI HDBaseT™ TRANSMITTER up to 330 Feet (2-way IR, RS-232, HDMI)

Name: Shinybow SB-6335T HDMI HDBaseT™ TRANSMITTER up to 330 Feet (2-way IR, RS-232, HDMI)
Brand: Shinybow
SKU: SB-6335T
Price: 299.00 USD
Availability: InStock
Rating: 4.5 (30 reviews)

4.5 30 reviews

$299.00 $399.00 Save 25% ($100)

Volume and Government pricing available - call (216) 798-7530 or request a quote.

Description :

The Shinybow SB-6335T HDBaseT™ Transmitter can transmit the HDMI signal, IR Remote signals input or output and RS-232 I/O series interface to the HDBaseT™ Receiver (SB- 6335R) via a single category LAN cable for the long distances up to a maximum 328 feet (100M). The Transmitter uses a single CAT6, CAT6a or CAT7 (UTP/FTP) category cable via a RJ-45 8P8C female socket. The LAN cable supports the 568a or 568b LAN color specification table. This product provides higher full HD HDMI 1.4a, HDTV resolution support for 480i/p, 720p,1080i/p or High 4K2K quality that are identical to the source high quality full HDMI 1.4 signals. The Transmitter is useful for sending the HDMI digital video & digital multi-channel audio format signals, IR remote in or out, RS-232 series in and out controls signals via a single category cable transmitted to the HDBaseT™ Receiver.

Inputs:
- 1x RS-232
- 1x HDMI
- 1x IR EXT port
Outputs:
- 1x CAT5/6 UTP

In stock. Ships fast

Estimated delivery: 3-6 business days

Request a Volume / GSA Quote

Quick Shipping

2-year warrantywith RMA support

Live expert help(216) 798-7530, M-F 9-5 ET

30-day returnsRMA support process

Secure checkout

PO/Net-30

Certified and compliant

REACH TAA Compliant

Product Features

HDBaseT™ Transmitter extends the HDMI over single CAT5e/6/6a category 328 feet /100M LAN cable
Transmits HDMI, IR in/out and RS-232 I/O series interface signals
Uses a single CAT6, CAT6a and CAT7 (UTP or FTP) category cable
Supports link speeds of up to 3.4 Gbps, HDMI 1.4, full HD 4K2K signal, HDCP compliant
Supports Digital RGB 36bits, HDMI digital video TMDS, digital multi-channel audio format
Extends higher quality full HD DVI video WUXGA 1920x1200 resolution
Supports High Definition worldwide range resolution 480p, 720p 1080i/1080p-60Hz and 4K2K
Extends long distances up to 328 feet (100M) between HDBaseT™ Transmitter and Receiver
Supports wall mount installation- total 10 pcs. into one 19 inch 4U rack mount
Power input via DC with low power consumption (Full load 750mA)
Power supply using universal power switch 50/60Hz,100~240VAC

Specifications

Type of Extender	HDBaseT™ Transmitter for HDMI over single category 328 feet /100M Cable
Input Signals	HDMI with Digital Video(TMDS)/Audio 0.5~1.0vPP, DDC 5Vpp
HDBaseT™ Supports	HDMI 1.4 Standard, DVI and HDCP Compliant
Video Support	HDMI and DVI TMDS format for 1920x1200 resolution up to 3.4 Gbps Digital RGB 36bits deep color, 3D 1.4a HDMI format
Audio I/O Support	Multi-channel Audio Formats 5.1 / 7.1, MAT(MLP), Dolby Digital, Dolby TrueHD, Dolby Digital Plus, DTS, DTSES 6.1, DTS-HD, DTS-HD-HRA, DTS-HD Master, (PCM-2CH)
Extend Distance	Up to 328 feet (100M) via (UTP or FTP CAT6 100M cable)
Cable Support	CAT6, CAT6a, CAT7 use UTP or FTP category cable
Supports HDMI Resolutions	480p, 720p 1080i/1080p@60Hz or 4K2K@24Hz
Scan Rate Accepted	Supports HDMI full HD Resolutions; Frequency 24Hz to 60Hz
Control	1x IR in, 1x IR out and 1x RS-232 I/O series interface
IR Infrared Frequency	38Khz
Safety Approvals	CE, FCC, VCCI, REACH & WEEE
Dimensions (LxWxH)	5.12 x 3.14 x 1.14 in (130x80x29mm)
Wall Mount	Wall mount pack (p/n:VM-1inch-L80MM)
Rack Mount	Total 10 pcs install into 19 inch 4U rack mount
Shipping Weight	0.375 kgs / 0.825 lb
Power Consumption	Max. 750mA (Full load 1080p-60Hz signal with use DC12V input)
Power Supply	Power Input +12VDC, 2A, (Universal Type 50/60Hz, 100~240 VAC)
