PSU-RED2-8-US Adder Redundant Dual AC Rack Power Supply Unit 8 port

PSU-RED2-8-US Adder Redundant Dual AC Rack Power Supply Unit 8 port

( 67 Reviews )

#PSU-RED2-8-US

$1880.00 $1692.00

Description :

The Adder PSU-RED2-8-US redundant Dual AC power supply (RED PSU) provides your installation with the power to grow on demand. Housed within a 1U 19-inch rack mount module, Adder PSU-RED2-8-US delivers up to eight lockable power 12VDC outputs, hot-swapable power modules and remote management.

Add to Cart

Description
Reviews (1)

Product Features

8 port independently controllable 12V outputs
2 hot swappable power modules
Controllable via secure HTTP interface
REST API for 3rd party control integration
500,000hrs MTBF ratings on power modules
12V to 5V cable converters available for units with 5V power feeds

Specifications

Mains inputs	2 x IEC 90-264VAC 47/63Hz input Efficiency 92% Power Factor 0.99 typical
Peripheral connections	1x 8p8c for 10/100 Ethernet connection.
Power outputs	8 x locking 3-pin DC connector, 12VDC 20W output. Each output is a Limited Power Service (LPS) to IEC 60950-1.
Physical design	Compact case, robust metal construction. Designed for 19 inch rack mounting: 435mm/17.13” (w), 44mm/1.73” (h), 275mm/10.8” (d), 4.5kg/9.9lbs.
Operating conditions	Temperature: 0 to 50ºC / 32 to 122ºF Humidity: 5 – 90% Non condensing Altitude: <2000Meters / 6500ft MTBF: 500,000hrs at full load @50C
Local client requirements	Browser versions: Internet Explorer® 10,11 Firefox 24 ESR and above Chrome 43
Approvals	CE, FCC, UL
