KVMSwitchTech Part #: AB-5659 In stock

16 Port HDMI Splitter Distribution Amplifier 3D with Infra Red Remote 1U Rackmount

Name: 16 Port HDMI Splitter Distribution Amplifier 3D with Infra Red Remote 1U Rackmount
Brand: KVMSwitchTech
SKU: AB-5659
Price: 795.00 USD
Availability: InStock
Rating: 4.6 (271 reviews)

4.6 271 reviews

$795.00 $1,200.00 Save 34% ($405)

Volume and Government pricing available - call (216) 798-7530 or request a quote.

Description :

KVMSwitchTech's AB-5659 is a one (1) input x sixteen (16) output HDMI Splitter distribution amplifier that allows users to connect any digital video source, such as: DVD, Satellite, Cable Box, and more with up to sixteen 16 digital HDMI displays. This 1U Rackmount 16 port HDMI Splitter, AB-5659 splits HDMI signal without signal loss maintaining high resolutions. It is a high quality HDMI distribution amplifier designed for HDMI Signal. Providing 1x input and 16 outputs, this unit supports data rates up to 2.25 Gbps. and enable 1080p HDMI formats and UXGA DVI resolution to LCDs and Plasma displays. Auto scan function software is built-in to extend HDMI Signal for long distance. This product is certified as being fully HDMI and HDCP compliant. It is also RoHS, CE, FCC compliant.

In stock. Ships fast

Estimated delivery: 3-6 business days

Request a Volume / GSA Quote

Quick Shipping

2-year warrantywith RMA support

Live expert help(216) 798-7530, M-F 9-5 ET

30-day returnsRMA support process

Secure checkout

PO/Net-30

Certified and compliant

REACH TAA Compliant

Product Features

Support 1x16 HDMI Splitter Distribution Amplifier
I/O Signals: HDMI with HDCP Digital Video and Digital Audio (PCM)
HDMI and HDCP compliant
Support link speeds of up to 2.25 Gbps (link clock rate of 225 MHZ)
Support Wide range of PC resolutions from XGA to UXGA 1600x1200 and HDTV/DTV resolutions 480i/480p, 576i/576p, 720p, 1080i & 1080p
Compatible with all HDMI devices, PC monitors, Plasma TV display and HDTV
Support Digital Video TMDS formats in Deep Color 12bits
Support color depth of up to 36 bits and ensures robust transmission of high-quality uncompressed video content, along with state-of-the-art uncompressed and setup boxes
Bi-direction color space conversion (SCS) between RGB and YCBCR color spaces with programmable coefficients
Auto-Scan input and outputs status via LED display on front panel
Control by Selection buttons on front panel and use IR Remote Controller
Support IR Extender port with 1000 feet long distance in rear panel
Support desktop with Ear mount and 19 inch Rack mountable type panel
Power supply DC12V, Universal Type switch 100~230VAC, 50/60Hz

Specifications

Type of Distributor	1x16 HDMI Splitter Distribution Amplifier
Signal Supports	HDMI Standard, DVI and HDCP Compliant
Video Supported	1080p HDMI formats and DVI UXGA 1600x1200 HD resolutions
Audio Supported	DTS-HD Master Audio, Dolby True - HD & Dolby Digital Plus
Type of Signal	TMDS Digital Video PCM Digital Audio
Compliant with HDMI Standard	HDMI and HDCP
HDTV Support	1080p HDMI formats and UXGA 1600x1200 resolution
Controls	Select buttons on the front panel, IR Remote and IR Extender
Data Rates	250Mbps to 2.25 Gbps
Pixel Clocks	25MHz to 225 Mhz
HDMI Cable Distance	30 fet at 2.25Gbps
Various video input interface supporting digital video standards such as
RGB/YCBCR	24/30/36bits
YCBCR	8/10/12/16/20/24bits
Double data rate interface for RGB/YCBCR	12/15/18bits
Infrared frequency	38KHz
Safety Approvals	CE, FCC, RoHS (2002/95/EC)
Dimensions	19 x 7.87 x 1.75 in (482 x 200 x 44 mm)
Power Supply: Output	12VDC 5A, Input: 100-240VAC, 50-60Hz 1.2A
Unit Weigh	4.26 lbs
