16x16 Multi Video Format Matrix Switch with HDMI, DVI, SDI, VGA, Fiber Optic support and TCP/IP Control


Description :



16x16 Multi Video Format Matrix Switch with 4KX2K Support

KVMSwitchTech's 16x16 Multi Video Format Matrix Switch with HDMI, DVI, SDI, VGA, Fiber Optic support also referred to as modular Matrix is the ultimate answer to cost–effective universal switching, whether analog or digital signals – this modular Matrix will let you plug various changeable I/O cards. It's a chassis designed for adding 16-inputs to 16-Outputs in a 3U frame. System Integrators and AV installers are constantly faced with challenges of running multiple analog and digital I/O’s when designing a system. This modular Matrix will provide various I/O with hot-swappable slots. You can now customize and choose the right card for different applications. This 16X16 multi-video matrix switcher supports different Video Signals with cross-switching ranging from VGA, DVI, HDMI, SD/HD/3G-SDI, to HDMI over twisted pair and fiber optic input and output cards. Every video or audio signal is transmitted and switched independently with power fail memory function and audio breakaway. This hdmi matrix unit is fully controllable through IR, RS232 and TCP/IP. Simply select the blend of analog or digital with stereo Audio Matrix cards that best fits your application, and then install them in order desired. Fully field upgradeable, as AV Signal routing needs change over time, now you can choose new matrix cards to adapt to new requirements. This 16x16 Multi video router is ideal for various commercial applications such as, control centers, smart lecture halls, medical, government and residential environments where signal management and distribution of high-resolution Video signals and audio is critical.

The related modules inputs/outputs are at the bottom of the page. Please call 234-380-5708 for pricing details.

16x16 Multi Video Format Matrix Switch with HDMI, DVI, SDI, VGA, Fiber Optic support and TCP/IP Control

Item Number: #MVID-MTX-1616-IP
Price: $9000.00
Sale Price: $4800.00

Availability: instock

Quantity:

Product Features



  • Flexible universal slots for various signal formats like VGA, SDI, DVI, HDMI, Fiber Optic and HDMI over CAT6
  • Front panel LCD- for operation and working status
  • Hot swappable with easy plug n play
  • Cross Switching - any input to any output
  • Backlit button provides label which is change-able for customizing
  • RS232 serial control port, using serial commands
  • TCP/IP Control via ethernet
  • Front panel security lock prevents unauthorized use when the matrix is installed in an unsecured environment
  • 9 Global presets- to save and recall the function
  • 3U Rack-Mountable aluminum enclosure
  • Dual-Internal international power supply (100Volt~240Volt AC, 50/60Hz) for world wide compatibility
  • Backed by 3-year full parts & labor warranty


Specifications

Chassis Input
16 x Input Cards
Chassis Output
16 x Output Cards
Bandwidth for each input/output
340 MHz (10.2 Gbps)
Input/ output impedance
75 ohms
Switching speed
200ns (max)
Gain
0 dB
Maximum delay
5nS (+/- 1nS)
Maximum pixel clock
165 MHz
Control

Serial control port
RS-232, 9-Pin female D Connector
Pin Configurations
2 = TX, 3 = RX, 5 = GND
Installation
Rack Mountable
Front panel control
Buttons
Options
TCP/IP (Ethernet Controller)
General

Frame Size
3U Rack chassis
Dual Internal Power Supply
110VAC ~ 240VAC, 50/60Hz
Humidity
10% ~ 90%
Temperature
-20 ~ +70 C
Power Consumption
50W
Case Dimension
W483 x H175 x D320mm
Product Weight
6.5 Kg
