6U 17" Ultra High Resolution 1920 x 1200 Rackmount LCD Monitor with DVI-D, HDMI, VGA, and Audio Connectors


#RKMTL-7U-17-UN
$2400.00 $1999.00


Description :

KVMSwitchTech's 6U 17" Ultra High Resolution Rackmount LCD, RKMTL-7U-17-UN TFT unit provides users with a variety of choices such as Wall Mounting or Rack mounting. These rack mount monitor units come with Industrial Grade Samsung LCD which provides users with crisp and clear image. These LCDs are a cost effective solution and save you valuable Rack space. Rack mount LCD units support simple plug and play functionality.

6U 17 Ultra High Resolution 1920 x 1200 Rackmount LCD Monitor with DVI-D, HDMI, VGA, S-Video and BNC Connectors




Product Features



  • 6U Rackmount 17" Widescreen LCD
  • 1920 x 1200 Native WUXGA Ultra high resolution
  • Support full HD with 1080p resolution
  • Green LED-backlit panel technology
  • 1.07 Billion true colors, 10-bit
  • Built-in HDMI, DVI-D, VGA, Audio
  • 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • 17" Touchscreen : Capacitive, Resistive (Optional)
  • 48V, 24V or 12VDC input (Optional)
  • MIL-Type or lockable Connector (Optional)

Specifications

LCD Panel
Size (diagonal)
17.1" TFT
Max resolution
1920 x 1200
Brightness (cd/m2)
300
Backlight
LED

Colors
16.7 Billion, 8-bit
Contrast ratio (typ)
800 : 1
Viewing angle (H/V)
178° x 178°
Active area (mm)
367 x 230
MTBF (hrs)
15,000
Signal input
HDMI / DVI-D / VGA / Audio
Environmental
Operating
0 to 55°C Degree
Storage
-20 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G Acceleration ( 11 ms duration )
Vibration
10~300Hz  .5G RMS Random Vibration
Casing Color
Black front panel ( RAL 9005 )
Dark grey rear case ( RAL 7037 )
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 48 Watt, Standby 5 Watt
Dimensions

Product
480 x 58 x 266 mm / 18.9 x 1.9 x 10.5 inch
Packing
529 x 124 x 451 mm / 20.8 x 4.9 x 17.8 inch
Weight

Net
6 kgs / 13.2 lbs
Certifications
CE, FCC, RoHS2 and Reach Compliant
