8x16 HDMI Matrix Switcher with RS232, IR and TCP/IP Control


#HDMODMTX-0816-IP
$5850.00 $4650.00


Description :



KVMSwitchTech's 8x16 HDMI Matrix Switch is designed to allow the switching and distribution of up to (8) source devices to up to (16) connected displays, via HDMI providing control options (dependent on module configuration). This HDMI Video Matrix offers unparalleled levels of flexibility, with an advanced modular design these models can be setup in a wide variety of combinations allowing users the ability to tailor the Matrix to their requirements by simply adding or removing the input or output modules as required. The HDMI Modular Matrix is supplied with single or dual removable internal PSU's which allows for easy inspection and maintenance with zero down time. In addition, this matrix also features IP control allowing users to access and control the matrix remotely and also allow additional options for integration of third-party control systems.




Product Features



  • HDMI, HDCP 1.1 and DVI 1.0 compliant
  • Interchangeable input and output modules
  • Input and output module types can be mixed and added in multiples of (8) from 8x8 (1 Input module, 1 Output module) up to 16x16 (2 Input modules, 2 Output modules) with HDMI connection type
  • Supports a wide range of PC and HDTV resolutions from VGA to WUXGA and 480i to 1080p
  • Supports pass-through of LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD Master Audio
  • Supports control of the matrix via RS-232, Telnet and Web GUI control
  • Supports (10) available preset settings
  • Supports (3) EDID modes: Standard, Dynamic and Manual (See Section 6.1 for details)
  • Dual removal power supply units
  • Supports HDMI cable input and output lengths of up to ~50ft/15M each way (1080p@8-bit resolution), 32ft/10M (1080p@12-bit resolution)


Specifications



Inputs
8 to 16 HDMI (Uncompressed AV and Data)
  • 1x 9pin Dsub (1x RS-232 Data)
  • 1x RJ45 (1x IP Control)
  • 1x USB Mini B (1x SERVICE Propriety Data)
  • 1x 3.5mm Stereo mini-jack (1x RESERVED Infra Red Receiver)
Outputs
8 to 16 HDMI (Uncompressed AV and Data)
PSU
110V/220V
Dimensions (WxDxH)
19 x 19 x 5.7 inches (482x484x145mm)
Net Weight
32 lbs / 14.4Kg
