- (8) HDMI source devices matrix switched to (8) HDMI output destinations
- HDMI digital video w/ embedded HDCP, DVI formats and CEC/HDCP 1.3 compliant
- Worldwide control EDID modes for HDMI full 4K2K (24/30Hz) HD video resolutions
- Link speeds of up to 6.75 Gbps (link clock rate of 340MbHz), Supports HDMI 4K2K, 1.4a 3D formats
- Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p, 1080i/p & 3860x2160p (24/30Hz)
- Compatible with all HDMI source devices, PC monitors, Plasma HD displays, HDTVs and audio receivers or audio amplifiers
- Digital video TMDS formats resolutions up to 4K2K with Deep color 36-bit
- Using the build-in booster, each HDMI Output port is capable of driving cable lengths for 1080p up to 98 ft (30M) & 4K2K up to 66 ft (20M)
- Digital Audio Support: Dolby TrueHD, Dolby Digital, Dolby Digital Plus/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX, PCM, PCM2, LPCM2
- Various User Interface control:
- Windows based GUI control via RS-232 port
- Front panel push buttons
- IR wireless remote control
- Ethernet switch control
- Third party RS-232 controller (via simple ASCII)
- Full function front panel controls: ALL / OFF / EDID / LOCK / RECALL / MEMORY / ENTER
- Support EDID Modes:
- Embedded EDID Modes: FSS/ H24-3D/ H24-3D-M/ H36-3D/ H36-3D-M/ 4K2K-3D / DVI-D 1920x1200-60Hz
- External modes: External modes : Learning mode-1 (Single Learning) & Learning mode-2 (Multiple Learning)
- Supports IR remotes and IR extenders for distances up to ~ 984 ft (300M) Maximum
- Supports Universal power adaptor AC100V~AC240V, 50/60Hz
Specifications
|
Type of Switcher
|
(8) Inputs to (8) Outputs 4K2K HDMI Matrix Switcher
|
|
HDMI Support:
|
HDMI 4K2K, 1080p-@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats
|
|
HDCP / CEC Support
|
HDCP 2.0 Compliant, CEC Compliant
|
|
Video Bandwidth
|
Double Data Rates: 340Mhz, Total 6.75Gbps bandwidth
|
|
Digital Video Support
|
HD: 480i/ 480p/ 720p/ 1080i/p and 4K2K up to 36bit deep color
|
|
Video Inputs
|
8x HDMI (HDMI or DVI digital source)
|
|
Video Outputs
|
8x HDMI with Booster output for 1080p up to ~98 feet (30M) & 4K2K up to ~66 feet (20M)
|
|
Switch Controls
|
- 1x Select & Function buttons on front panel (Data status via LCM panel show out)
- 1x IR Remote Controller (switch control)
- 1x IR External port (switch control via 3.5mm OD Jack)
- 1x RS-232 series interface (switch control)
- 1x Ethernet series interface (switch control)
|
|
Source Status
|
Input status LEDs indicates presence of a live signal
|
|
Function Control Keys
|
ALL, OFF, RECALL, ENTER, MEMORY, LOCK, EDID, Destination button 1 thru 8, Source button 1 thru 8
|
|
(7) EDID Management
|
- 1. Select Embedded EDID modes : Mode1: FSS, Mode2: H24-3D, Mode3: H24-3D-M, Mode4: H36-3D, Mode5: H36-3D-M, Mode6: 4K2K-3D, PCM-2CH, Mode7: DVI-D 1920x1200-60Hz
- 2. Select LEARNING Mode: Learning destination EDID to link source
|
|
Infrared Frequency
|
38Khz
|
|
Video Booster
|
HDMI output for 1080p with lengths up to 98 ft (30M)/4K2K up to 66 ft (20M)
|
|
IR External Distance
|
~984 ft/300M maximum
|
|
HDMI I/O Connector
|
HDMI Type A - SMD 19pin female type
|
|
Temperature
|
32°F-100°F Operation (0°C-32°C)
|
|
Dimensions (LxWxH)
|
19 x 9.85 x 1.75 in (482x250x44 mm)
|
|
Rack Mount
|
1RU High 19 in Rack Mount #1U-440L (with rack mount)
|
|
Power Supply
|
DC12V, 5A, Power Input: AC 100~240VAC 50/60Hz (universal type supply)
|
|
Safety Approvals
|
CE, FCC, RoHS, REACH
|
|
Product Weight
|
8.15 lb/3.65 Kg
|
|
