HDMI Quad Screen Real Time Multiviewer with Telnet TCP/IP Control

$2700.00 $1999.00


Description :

KVMSwitchTech's HDMI-PIP-4PHDMI Quad Screen Real Time Multiviewer with TCP/IP Control is a High performance, High speed zooming/shrinking system that can be easily configured and controlled for quad or picture-in-picture Video processing. Allowing 4 different HDMI input sources to be freely selected and arranged on one single display with supporting resolution up to 1080p and audio up to 8Ch 192kHz for both inputs and outputs. This HDMI Quad Screen MultiviewerHDMI-PIP-4P offers screen setting hot keys with Infra Red ( IR) and RS 232 to control and switch to the output display. Please email us at sales@kvmswitchtech.com for Reseller Pricing.

HDMI Quad Screen Real Time Multiviewer with Telnet TCP/IP Control


Product Features



Real Time HDMI Quad Multiviewer

  • Seamless Switching between channels and Windows
  • Zoom and Shrink 4CH input image and/or overlay
  • Supports PIP, POP and multi-windows display
  • Supports OSD, RS 232 Remote and on-panel controls
  • Fade-In-Out, Chromakey, Mirror and rotation (90° left & right and 180° up & down) functions
  • 8 Screen setting hot keys and extra 4 customized favorite screen setting
  • Support individual channel size and position adjustment


Video Bandwidth
Input Port
Output Port:
1 x HDMI
ESD Protection
Human body model: ±8kV (air-gap discharge) / ±4kV (contact-gap discharge)
Power Supply
12V/3A DC (US/EU standards, CE/FCC/UL certified)
Dimensions (WxDxH)
17 x 6.8 x 1.73 in (432 x 172 x 44mm)
4.9 lbs
Chassis Material
Silkscreen Color
Operating Temperature
32°F ~ 104°F (0°C ~ 40°C)
Storage Temperature
-4°F ~ 140°F (-20°C ~ 60°C)
Relative Humidity
20 ~ 90% RH (non-condensing)
