N117-S1601b Cyberview 1U 17" Rackmount Monitor Keyboard Drawer with combo KVM Switch USB and PS2 Trackball, 16 Ports

( 116 Reviews )

$2100.00 $1794.00

Description :

N117-S1601b 17" Cyberview Rackmount Keyboard Monitor with 8 port USB and PS2 KVM Switch is a combination of Keyboard, Video and trackball Mouse (KVM) in 1U Rack drawer. This KVM Drawer unit comes with a combo interface cable which supports USB and PS2 Keyboard interface.Please note cables must be purchased separately.

Add to Cart

Product Features

17" Rack Monitor Keyboard with 16 Port USB and PS2 KVM Switch in 1U
Cost efficient Combo KVM integration
"One Man" installation slides for easy, quick installation
Mix PS/2 USB & SUN with Multi-Platform switch capability
Multiple Keyboard language selection with trackball
Side rails with fixed positions to prevent drawer movement when typing
Enhanced aesthetics with new molded front panel and two point lock

Specifications

Environmental
Operating Temperature	0° to 55°C Degree
Storage Temperature	-20° to 60°C Degree
Relative Humidity	5-90%, non-condensing
Shock	10G acceleration (11ms duration)
Vibration	5~500Hz 1G RMS Random vibration
LCD	Samsung LCD Panel
Diagonal Size	17" TFT LCD
Max. Resolution	1280 x 1024
Brightness (cd/m²)	250
Color Support	16.7 Mil
Contrast Ratio(Typ)	1000:1
Viewing Angle (H/V)	160° x 160°
Display Area (mm)	337 x 270
Tr Response Time (ms)	1.3
VGA Signal	Input Analog RGB, 0.7Vp-p
Sync. Type	Separate H/V, Composite, SOG
External Connection
Power Input	Auto sensing 100 to 240VAC, 50 / 60Hz via IEC Connector
Video Input	VGA 15-Pin connector
Dimensions
Product (WXDXH)	17.4 x 24.4 x 1.75 inches
Packaging (WXDXH)	23.6 x 30.3 x 7.1 inches
Weight
Net	42lbs
Gross	54lbs
Certifications	cUL, CE, FCC, Reach & RoHS2

View User Manual
