PSU-RED2-16-US Adder Redundant Dual AC Rack Power Supply Unit 16 port

Description :

The Adder PSU-RED2-16-US redundant Dual AC power supply (RED PSU) provides your installation with the power to grow on demand. Housed within a 1U 19-inch rack mount module, PSU-RED2-16-US delivers up to sixteen lockable power 12VDC outputs, hot-swapable power modules and remote management.



Item Number: #PSU-RED2-16-US
Price: $2200.00
Sale Price: $1980.00

Availability: instock

Quantity:

Product Features



  • 16 port independently controllable 12V outputs
  • 2 hot swappable power modules
  • Controllable via secure HTTP interface
  • REST API for 3rd party control integration
  • 500,000hrs MTBF ratings on power modules
  • 12V to 5V cable converters available for units with 5V power feeds


Specifications

Mains inputs
2 x IEC 90-264VAC 47/63Hz input
Efficiency  92%
Power Factor 0.99 typical
Peripheral connections
1x 8p8c for 10/100 Ethernet connection.
Power outputs
16 x locking 3-pin DC connector, 12VDC 20W output. Each output is a Limited Power Service (LPS) to IEC 60950-1.
Physical design
Compact case, robust metal construction. Designed for 19 inch rack mounting: 435mm/17.13” (w), 44mm/1.73” (h), 275mm/10.8” (d), 4.5kg/9.9lbs.
Operating  conditions
Temperature: 0 to 50ºC / 32 to 122ºF
Humidity: 5 – 90% Non condensing
Altitude: <2000Meters / 6500ft
MTBF: 500,000hrs at full load @50C
Local client requirements
Browser versions:
Internet Explorer® 10,11
Firefox 24 ESR and above
Chrome 43
Approvals
CE, FCC, UL
