RPW719-HDMI Cyberview 7U 19" WideScreen HDMI Rackmount LCD Monitor


#RPW719-HDMI
$1200.00 $975.00


Description :

RPW719-HDMI Austin Hughes Cyberview 7U 19" Widescreen HDMI Rackmount LCD allows users to capture and Monitor data. These Widescreen rackmount lcd display units come with industrial grade Samsung LCD which provides users crisp and clear image. These LCDs are a cost effective solution and save you valuable Rack space. Rackmount LCD units support simple plug and play functionality.




Product Features



  • High resolution 1440 x 900 for RP-W719HDMI
  • Ideal for CCTV security & industrial control
  • VGA + HDMI w/ Speaker + BNC + S-Video + Audio (Standard connectors on this unit)
  • 7U 19" Widescreen
  • SDI and Multi Display Control(Optional)
  • DC Power (Optional)
  • Touch Screen (Optional)

Specifications

LCD
19" Wide Screen Samsung TFT
Max. Resolution
1440 x 900
Brightness (cd/m2)
300
Contrast Ratio
1000 : 1
Viewing Angle (H x V)
160 / 160
Color Support
16.7 m
Active Area (mm)
408 x 255
Response Time Tr + Tf (ms)
5
LCD Panel MTBF (hrs)
50,000
Signal Input
VGA /HDMI w/ Speaker /BNC / S-Video/ Audio
Sync. Type
Separate H/V, Composite, SOG
Resolution
800 x 600, 60/ 70/ 72/ 75 Hz
1024 x 768, 60/ 70/ 75 Hz
1152 x 864, 60/ 70/ 75 Hz
1280 x 720, 60/ 75 Hz
1440 x 900, 60 Hz
Plug & Play DDC
EDID 1.3
Connector
VGA + HDMI w/ speaker + BNC + S-Video + Audio
Power Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
Max. 48 Watt, standby 5 watt
Compatibility
Multi-Platform - Mix PCs, SUNs, IBMs, HPs & DELLs
Operation
0° to 50°C Degree
Storage
-5° to 60 °C Degree
Relative Humidity
5~90%, Non-condensing
Shock
10G Acceleration (11ms duration)
Vibration
5~500Hz 1G RMS Random vibration
Product Dimension (W x Hx D)
18.9 x 12.2 x 2.3 inches
Packing Dimension (W x H x D)
20.8 x 19.5 x 4.9 inches
Net Weight
6 kg/13 lbs
Gross Weight
8 kg /18 lbs
