Secure 8-Port, Single-Head DP KVM Switch with 4K HD Support


#CK4-P108
$2640.00 $2199.00

Part #CK4-P108

Secure 8-Port, Single-Head DP KVM Switch with 4K HD Support

Description: The Secure KVM emulates (simulates) the presence of a keyboard and mouse for every attached computer through a USB cable. Both selected and non-selected computers maintain a constant connection with the unit’s keyboard and mouse emulation controllers, allowing for ultra-fast switching and restricting discovery of newly connected peripherals during switching operations. Emulation of keyboard and mouse also prevents direct connection between the peripherals and the connected computers, shielding systems from potential vulnerabilities.The KVM can simulate a generic EDID, allowing it to operate most of the connected DP monitors in the market. Both selected and nonselected computers maintain a constant connection with the unit’s video and EDID emulation controllers, allowing for ultra-fast switching and restricting discovery of newly connected monitors during switching operations. The unit prevents unwanted and unsecure data from getting transmitted between the computers and the display.


Features:

  • Supports Windows, Mac and Linux OS
  • Single-head DisplayPort video interface
  • 4K HD resolution – supports up to 3840 x 2160 @ 30Hz
  • External power supply – Level VI efficiency
  • Computer interface isolation while powered or unpowered
  • Ensures all user data is completely isolated and no data is ever stored
  • No external interfaces can be used, only keyboard and mouse accepted
  • Secure channel switching with leak prevention, no hotkeys
  • Front panel tactile buttons for secure channel switching and LED channel indicators
  • Peripheral and authentication ports isolation for secure usage
  • Tamper evident label and anti-tampering technology
  • No wireless devices connected
  • Ensures only trusted admin gains access
  • Government Operations
  • Defense Applications
  • Secure Control Rooms
  • Corporate Communications
  • Server Operations
  • Educational Administrations
  • Medical Facilities
  • Banking Network
  • Insurance Data Centers
  • Transit Management
  • Industrial Operation
  • Intelligence Communications

Specifications:

VIDEO
Format DisplayPort
Max. Pixel Clock 248 MHz
Input Interface (8) DisplayPort 20-pin
Output Interface (1) DisplayPort 20-pin
Resolution Up to 4K (3840×2160 @30Hz)
DDC 5 volts p-p (TTL)
Input Equalization Automatic
Input Cable Length Up to 20 ft.
Output Cable Length Up to 20 ft.
Data Rate 1.65 Gbps per color
AUDIO
Audio Input (8) 3.5mm stereo audio
Audio Output (1) 3.5mm stereo audio
USB
Input Interface (8) USB Type B
Output Interface (2) USB 1.1 Type A for KM Devices
Emulation USB 1.1 and USB 2.0 Compatible
CONTROL
Front Panel Front panel SELECT buttons
OTHER
Power External 100-240 VAC/ 12VDC3A @ 36W
Dimensions 17.0” W x 1.76” H x 6.69” D
Weight 6.3 lbs
Approvals NIAP PP 4.0, UL, CE, ROHS Compliant
Operating Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Humidity Up to 80% (No Condensation)
