UVC OPHIT S300 – Multi-format converter


$3999.00 $2975.00

This Universal Video Converter (Model: UVC-S300) is powerful Multi-Format Video input/output Converter which is able to convert Digital to Analog. This unit has digital HDMI port as input formats and Composite (RCA & BNC) / S-Video / D-SUB / DVI as output formats. The input video signal (HDMI) is converted 5(five) output formats as analog Composite (RCA and BNC) / S-Video / D-SUB and 1(one) digital DVI output. The unit has a unique function as cropping which is available in the S-Video /composite output formats. The unit is designed with a stringent safety requirements such as the medical environment and other similarly restriction location.


Features

  • Convert Digital to Analog video signal
  • Input format : HDMI
  • 5 Output formats : D-Sub, DVI, S-Video, Composite (RCA and BNC)
  • 5 Simultaneous Outputs.
    •  Output of DVI / D-SUB outputs to the same size screen when HDMI Inputs (NO Crop)
  • Output of S-video / Composite outputs to down scaling when HDMI
    •  Input available for 7types of cropping in S-VIDEO /Composite output using by Dip Switch.
  • Output of S-video / Composite outputs to down scaling when HDMI
    • Inputs available for any cropping position in S-VIDEO /Composite
    • output using by communication commands from system’s I2C signal line.
  • NTSC/PAL Output is selectable by Dip Switch (S-video / Composite)
  • Available for RCA and BNC port output simultaneously as composite output.
  • DVI 1.0 Compliant
  • EMC & Safety : CE, UL, FCC
  • Connector :
    • Input : HDMI(female) x 1
    • Output :
      • DVI 24Pin(female) x 1, D-sub(female) x 1
      • S-video(female) x 1, Composite(BNC x 1, RCA x 1)
  • Supporting Resolution
    • Input :
      • 1024×768@50/60Hz
      • 1280×1024@50/60Hz
      • 1920×1080@50/60Hz
    • Output :
      • DVI : 1024×768@50/60Hz,1280×1024@50/60Hz, 1920×1080@50/60Hz (Convert and Bypass)
      • D-Sub: 1024×768@50/60Hz, 1280×1024@50/60Hz, 1920×1080@50/60Hz (Convert and Bypass)
      • S-video : NTSC-M or PAL-BGHI (Crop Image)
  • Power Consumtion : 9W (Max)
  • Power Supply : 100-240 V 50-60Hz, DC 12V, 2.5A
  • Dimensions : 200mm(W) x 137mm(D) x 30mm(H), Tolerance: ± 0.1mm
  • Operating Temperature Range : 0°C ~ 45°C
  • Storage Temperature Range : -10°C ~ 70°C

Package

  • UVC-S300
  • HDMI to HDMI cable (Length : 1.0 m)
  • User’s manual

Ordering Information

  • UVC-S300
