00-00411 Icron Ranger 2324 USB 2.0 Four Port Multimode Fiber 500m Extender

$1899.00 $1499.00

Description :

00-00411, Icron Ranger 2324 USB 2.0 four port Multimode Fiber 500m extender allows users to extend USB 2.0/1.1 connections up to 500m using OM2 (or better) fiber optic cable. This 00-00411, 4 port USB 2.0 Icron Ranger 2324 multimode fiber extender supports data rates at up to 480 Mbps and is plug and play – no software drivers required – for all major operating systems: Windows®, macOSTM, and Linux®. Additionally, this ExtremeUSB® based USB 2.0 multimode fiber extender system is FCC/CE Class B certified and ideal for use with all USB peripherals including: keyboards, mice, interactive white boards, flash drives, hard drives, audio devices, web cameras and any other USB 2.0 or 1.1 device.


Product Features


  • 4-port USB 2.0 extender supporting all USB 2.0/1.1 devices up to 480 Mbps
  • Up to 500m extension using OM2 multimode fiber
  • Integrated hub supplying up to 1 Amp to each USB port; 2.5 Amps total shared
  • Electrical isolation
  • Mass Storage Acceleration for USB 2.0 device bulk transfers
  • Metal enclosures with FCC/CE Class B certification
  • Two year warranty
  • ExtremeUSB® suite of features:
    • Transparent USB extension
    • True plug and play; no software drivers required
    • Works with all major operating systems: Windows®, macOSTM, and Linux®



  • Direct connect up to 500m (1.640 ft) over multimode OM2; up to 275m (902 ft) over OM1
  • USB 2.0: up to 480 Mbps
  • USB 1.1: up to 12 Mbps
LEX (Local Extender)
  • USB Connector: 1 x USB Type B Receptacle
  • Link Connector: 1 x SFP Duplex LC
  • Dimensions: 100.0mm x 76.0mm x 26.0mm (3.9″ x 3.0″ x 1.0″)
  • Mounting: 4 surface mounting holes or optional mounting kit available
  • Enclosure Material: Silver anodized aluminium
REX (Remote Extender)
  • USB Connector: 4 x USB Type A Receptacles
  • Link Connector:  1 x SFP Duplex LC
  • Available Current: up to 1 Amp to each USB port; 2.5 Amps total shared
  • Power Supply: 100-240V AC Input, 24V 1A DC Output
  • Dimensions: 100.0mm x 76.0mm x 26.0mm (3.9″ x 3.0″ x 1.0″)
  • Mounting: 4 surface mounting holes or optional mounting kit available
  • Enclosure Material: Silver anodized aluminium
  • Operating Temperature: 0C to 50C (32F to 122F)
  • Storage Temperature: -20C to 70C (-4F to 158F)
  • Operating Humidity: 20% to 80% relative humidity, non-condensing
  • Storage Humidity: 10% to 90% relative humidity, non-condensing
  • EMC: FCC (Class B), CE (Class B)
  • Environmental: RoHS2, REACH, Conflict Minerals
SUPPORT Warranty: 2-year
