10.4" Rackmount LCD Monitor with VGA and Composite Video RCA and S-Video Interface

Name: 10.4" Rackmount LCD Monitor with VGA and Composite Video RCA and S-Video Interface
Brand: KVMSwitchTech
SKU: KVMRMM-101V
Price: 1200.00 USD
Availability: InStock
Rating: 4.9 (67 reviews)

4.9 67 reviews

$1,200.00 $1,500.00 Save 20% ($300)

Volume and Government pricing available - call (216) 798-7530 or request a quote.

Description :

This 10.4" Rackmount LCD monitor with VGA and Composite video RCA/S-Video interface, KVMRMM-101V allows users to capture and Monitor data. These composite rack mount LCD monitors come with industrial grade LCD which provides users crisp and clear image. These LCDs are a cost effective solution and save you valuable Rack space. Rack LCD units support simple plug and play functionality.

In stock. Ships fast

Estimated delivery: 3-6 business days

Request a Volume / GSA Quote

Quick Shipping

2-year warrantywith RMA support

Live expert help(216) 798-7530, M-F 9-5 ET

30-day returnsRMA support process

Secure checkout

PO/Net-30

Certified and compliant

REACH TAA Compliant

Product Features

10.4” TFT LCD display (1024 x 768 Resolution) in 5U (8.75”) of Rack space.
ARGB (Analog RGB VGA 15PIN ) and Composite Video RCA/S-Video Signal inputs
Housed in rugged steel construction with a black powder coat finish
VGA cable, AC/DC adapter and power cord included
Lexan™ Screen protection available (L) (Optional)

Specifications

Dimensions	19.0" (W) x 8.75" (H) x 2.40" (D).
Weight	10 lbs
Power	110 - 240 VAC, 50/60 Hz. 60 Watts max
On-Screen Controls	Brightness, Contrast, Horizontal & Vertical Position, Auto Adjust, OSD H & V Position, Input Select Color Temp., Reset.
Plug & Play	DDC1 and DDC2B
Temperature	Operating: 0c to 50c Storage: -20c to 60c
Humidity(Operating)	10 to 90% RH (max)
Input Signal (VGA)	RGB Analog Video, TTL H & V sync
Input Signal (Digital)	Composite Video RCA and S-Video
Input Connectors	Analog: 15 Pin mini D-Sub Composite Video: RCA / S-Video - 4pin mini din
Colors Available	Black
Display Type	Active Matrix TFT LCD
Display area	10.4” Diagonal
Colors Displayed	262K Colors
Contrast Ratio	500:1 typ
Brightness	350 cd/m2 typ
Viewing Angle	Horizontal: 178 Vertical: 178
Response Time	40ms Typ
Resolution	VGA up to 1024 x 768
Horizontal Frequency	31.5 to 80KHz.
Vertical Frequency	56 to 75 Hz.
Screen Protection(Optional)	Lexan™
