1U 17" HDMI Ultra High Resolution 1920 x 1200 Rackmount Monitor Keyboard Drawer with combo USB and PS2 Interface Touchpad


#RKD-KVM-17-HDHDMI
$2700.00 $2499.00


Description :

1U 17" Ultra High Resolution 1920 x1200 HDMI Rackmount Monitor Keyboard Drawer, RKD-KVM-17-HDHDMI is a combination of Keyboard, HDMI Video and touchpad or trackball Mouse (KVM) in 1U Rack drawer. This HDMI Rackmount LCD Keyboard unit comes with a combo interface Cable which supports both USB and PS2 Keyboard interface.




Product Features



  • 1U 17" Widescreen Rackmount Monitor Keyboard Console Drawer with HDMI input
  • 1920 x 1200 1080p native Ultra High resolution
  • Support Full HD with 1080p resolution
  • Support Windows 7 / Vista / XP / Linux / Mac OS X
  • 104-key Keyboard with either touchpad or trackball
  • Enhanced aesthetics with new molded front panel and two point lock
  • 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • S-Video + Composite ( BNC ) & Audio input(Optional)
  • 48V, 24V or 12VDC input (Optional)
  • MIL-Type or lockable connector (Optional)

Specifications

LCD Panel
Size (diagonal)
17.1" TFT
Max resolution
1920 x 1200
Brightness (cd/m2)
210
Backlight
LED

Colors
1.07 Billion, 10-bit
Contrast ratio (typ)
800 : 1
Viewing angle (H/V)
178° x 178°
Active area (mm)
367 x 230
MTBF (hrs)
15,000
Signal input
HDMI
Environmental
Operating
0 to 50°C Degree
Storage
-5 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G Acceleration ( 11 ms duration )
Vibration
5~500Hz 1G RMS Random Vibration
Casing Color
Black ( RAL 9005 )
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 48 Watt, Standby 5 Watt
Dimensions

Product
17.4 x 18.9 x 1.73 Inches
Packing
 23.4 x 33.9 x 5.5 Inches
Weight

Net
24 lbs
Certifications
CE, FCC, RoHS
