Cyberview RP-K617 6U 17" 4K Rackmount LCD with DisplayPort and HDMI Connectors
#RP-K617
$1899.00
$1662.00
Cyberview RP-K617 is a sleek 6U 17" 4K LED rackmount LCD monitor equipped with a built-in On-Screen Display menu, tailored to streamline administrative tasks across multiple PCs. Within the RP series lies an economical rack mount LCD solution, perfectly suited to accommodate your restricted IT budget while maximizing space efficiency and offering extensive customization options.
Features:
6U 17" 4K LCD display panel
3840 x 2160 native resolution / 16.7M colors ( 8-bit )
1920 x 1080 & 1920 x 1200 resolution support
Display port 1.2 + HDMI 1.4 + HDMI 2.0 video input
PIP Sub-screen & PBP Dual-screen viewing efficiency
Built-in dual stereo speakers
2-year standard warranty ( upgradable up to 5 years )
RP-K617 Specifications
| Mechanical | |||||||
| Product Dimensions (H x W x D) | 10.5 x 18.9 x 1.9 in ( 266 x 480 x 48 mm ) |
||||||
| Package Dimensions (H x W x D) | 17.8 x 20.8 x 4.9 in ( 451 x 529 x 124 mm ) |
||||||
| Net Weight | 9.2 lb ( 4.2 kg ) | ||||||
| Gross Weight | 13.6 lb ( 6.2 kg ) | ||||||
| Console Ports | |||||||
| Video Input | DisplayPort 1.2 + HDMI 1.4 + HDMI 2.0 | ||||||
| LCD Screen | |||||||
| LCD panel size ( diagonal ) | 17.3" | ||||||
| Backlight type | LED | ||||||
| Native resolution | 3840 x 2160 | ||||||
| Brightness (cd/m2) | 400 | ||||||
| Colors | 16.7 M, 8-bit | ||||||
| Contrast Ratio (typ) | 1000 : 1 | ||||||
| Viewing angle ( L/R/U/D ) | 89/89/89/89 | ||||||
| Response time ( ms ) | 30 | ||||||
| Dot pitch ( mm ) | 0.0995 | ||||||
| Display area ( mm ) | 382.12H x 214.94V | ||||||
| Surface treatment | Anti-glare | ||||||
| Surface hardness | 3H | ||||||
| MTBF (hrs) | 20,000 | ||||||
| Audio Option | |||||||
| Speaker | 2x 2W (Dual Stereo) | ||||||
| Input Connector | 3.5mm stereo jack | ||||||
| Input Impedance / Power level | 30Ω / 750mV | ||||||
| Output Connector | 3.5mm stereo jack | ||||||
| Output Impedance / Power level | 30Ω / 2.8V | ||||||
| Power | |||||||
| Power Input | Auto-sensing 100 to 240VAC, 50 / 60Hz | ||||||
| Power Consumption |
|
||||||
| Environmental | |||||||
| Operating Temperature | 0 to 55°C Degree | ||||||
| Storage Temperature | -20 to 60°C Degree | ||||||
| Operating Humidity | 20~90%, non-condensing | ||||||
| Relative Humidity | 5~90%, non-condensing | ||||||
| Operating Altitude | 16,000 ft | ||||||
| Non-operating Altitude | 40,000 ft | ||||||
| Shock | 10G acceleration (11ms duration) | ||||||
| Vibration | 10~300Hz 0.5G RMS random vibration | ||||||
| Regulatory Compliance | |||||||
| EMC | FCC & CE certified | ||||||
| Safety | CE / LVD certified | ||||||
| Environment | RoHS2 & REACH compliant |
