HDBaseT HDMI Extender Receiver up to 330ft


$360.00 $195.00

Description :

The HDBaseT HDMI ExtenderREC-HDB-1P is an HDMI Version 1.4 Receiver that supports all the latest audio formats such as Dolby True HD, DTS-master, etc… and all seven (7) types of 3D. This HDBaseT HDMI Extender CAT5/5e/6/7 Receiver (Transmitter sold separately) is designed using technology which allows full 3D at 1080p up to 330 feet. The REC-HDB-1P not only supports High definition Video and Audio but also IR and RS-232. Front panel LED status display indicates a valid HDMI source, connection between the Receiver and transmitter and power. Built-in mounting tabs for surface mounting. Also supports DVI with use of an external adapter (not included). Note that DVI does not support audio.




Product Features



HDBaseT HDMI Extender

  • HDMI Over CAT5/5e/6/7 receiver
  • HDMI Digital Video/Audio and Video TMDS format with HDCP compliant and supports HDBaseT specifications
  • Supports all latest Audio formats such as Dolby True HD, DTS-master, etc…
  • 3D Enabled
  • Support link via using the CAT5/5e/6/7 UTP/STP Cable
  • Support link speeds of up to 3.4Gbps
  • Support Digital RGB 36bits HDMI TMDS format deep color
  • Extension with high quality video 1920x1200
  • Support HD High Definition full range resolution 408p, 720p 1080i/1080p
  • Receiver Support IR EXT and RS-232 control Display
  • Extended Long distance CAT6/7 330 feet (100m), CAT5e 200 feet (75m), CAT5 100 feet (35m)
  • Surface mountable ready
  • Easy to install without any adjustments
  • Power DC input with low power consumption (Full load 480mA)
  • Power supply using universal power switch DC 12V/1250mA


Specifications

Type of Extender
HDMI signal over CAT5/5e/67 Cable Receiver
Input Video Signals
HDMI with Digital Video (TMDS)/Audio .5~1.0vPP, DDC5Vpp
Video
  • HDMI and DVI formats for 1920x1200 resolution up to 3.4 Gbps
  • Digital RGB 36bits HDMI TMDS format deep color
Audio
  • DTS-HD Master Audio
  • Dolby True-HD
  • Dolby Digital Plus, etc..
Support HD Resolution
408p, 720p, 1080i/1080p
Scan Rate Accepted
HDMI Resolution 50Hz and 60Hz
Control Link Series
IR Extend and RS-232 series interface via a PC
IR Infrared Frequency
38Khz
Extend Distance
  • CAT6/7 330 ft (100m)
  • CAT5e 200 ft (75m)
  • CAT5 100 ft (35m)
Dimensions (LxWxH)
9.45 x 4.72 x 1 in (240 x 120 x 25 mm)
Product Weight
2 lbs
Power Supply
DC12V/2A (consumption 1680mA Max)
Universal Switch Type
50/60Hz, 100~230 VAC
Ships with North American Power Cord
