Ophit DDA DVI-D to VGA Adapter

Description :

This DVI-D to VGA digital to analog converter, SCA-DVI-VGA converts DVI-D input from your PC to be displayed on analog VGA Monitors or projectors. This DVI-D to VGA converter, SCA-DVI-VGA does not require external power supply (Optional power supply is available). This DVI to VGA converter eliminates the need to buy additional DVI Monitors. The unit does not auto compensate so you need to specify the desired video resolution for the VGA monitor.


Item Number: #SCA-DVI-ANA
Price: $295.00
Sale Price: $197.00

Availability: instock


Product Features


  • Input Connector- DVI-D SINGLE LINK
  • Output Connector- VGA 15 pin
  • Compatible with DVI-D Single link standard (DDWG)
  • Optional external power is available if needed
  • Units are preset to 1280x1024 video resolution (Please specify needed resolution at the time of placing the order)
  • Supports WUXGA|1900x1200|, UXGA|1600x1200|, SXGA|1280x1024|, XGA|1024x768|, SVGA |800x600|, VGA|640x480|and some wide screen formats
  • HDCP Compliant


DVI-D to VGA Converter Specifications

Frequency Bandwidth
1.65GHz (Single Link)
Power Consumption
1.8W (Max)
13.8 inches
Dimensions (WxDXH)
1.5 X 3 X 0.6 inches
Storage Temperature
20°C to +70°C
Operating Temperature
0°C to +50°C
Power Supply (Optional)
-0.3- 5.5 V
Relative Humidity
10-80 % Non Condensing
Lead Solder Temperature
260°C, 10 seconds
