Shinybow SB-5470M 4x2 Component Video/Audio Matrix Switcher + IR METAL w/Rack Mount

$399.00 $349.00

Description :

The SB-5470 is a 4x2 Matrix Switcher that switches 4 Inputs Component (YPbPr), and Left & Right Analog Audio with IR remote. SB-5470 is a rugged 4x2 switcher, offering flawless and seamless switching and crystal-clear distribution of all HDTV video formats as well as audio signals. SB-5470 accepts up to four different input sources and you can seamlessly switch (select) any of these inputs to drive 2 outputs, without any signal degradation. It is universally compatible with all HDTV formats: 480i, 576i, 480p, 576p, 1080i, 720p and 1080p.

SB-5470 is a versatile and compact State of the Art switcher of choice when you need high-quality and reliable switching. The Switch can be controlled by its front-panel manual control button, or IR remote, and convenient front-panel LED's indicate which input has been selected for both outputs.

Metal Chassie with removable rack mount brackets (included)


Product Features


  • Metal Chassie with removable rack mount brackets (included)
  • Inputs: 4 x Component Video (YPbPr), 4 x Stereo Audio input
  • Outputs: 2 x Component Video (YPbPr), 2 x Stereo Audio Outputs
  • Switch easily between any four Component Video sources
  • Maintains 480i, 480p, 576P, 720p, 1080i and 1080p resolutions
  • Discrete IR remote (included)
  • Easy to install and simple to operate
  • Also can be used for Composite Video switching (will not do conversion between Component or Composite).


Video Amplifier Bandwidth
200 MHz
Maximum Resolution
  • 4 Component Video (RGB, YPbPr)
  • 4 Left & Right Audio (RCA-Phono)
  • 2 Component Video (RGB, YPbPr)
  • 2 Left & Right Audio (RCA-Phono)
Power Consumption
12VDC .66mA
Switcher Size: (WxDxH)
9.25 x 5.5 x 1.73 inches
