4x4 DVI and HDMI Quad Screen Multiviewer and Video Wall Processor

$4500.00 $2499.00

Description :

KVMSwitchTech's VW-PIP-4P4x4 DVI and HDMI Quad Screen Multiviewer and Video Wall Processor is a powerful, universal and user-friendly image analyzing processor with 4 DVI input ports and 4 output ports. It is not only a 4x4 Matrix Switcher, but also a Multi-viewer Video wall processor that supports PiP (Picture in a Picture), PoP (Picture outside a Picture) and split screen display. Using the provided GUI interface, the location of the PIP and POP can be placed anywhere on the display simply by dragging and dropping the image. As a Video wall processor, any one of the input sources can be split to 4 Horizontal mounted displays or to 3 Vertical mounted displays. VW-PIP-4P has the capability to Zoom-in on one image 3x or 4x (per Output). The VW-PIP-4P can mix inputs with any combination into one image, and then display that to any or all the outputs. It also supports output resolution change, contrast & brightness adjusting, horizontal and vertical zooming and moving, and bezel adjustment. VW-PIP-4P offers various ways for system control through its RS232 serial port, USB interface, and the TCP/IP network port. It can be controlled easily by using the included control software. Applications include TV broadcasting, meeting rooms, network operations center, medical institutions, command & control centers.

4x4 DVI and HDMI Quad Screen Multiviewer and Video Wall Processor

Product Features


  • Supports PiP (Picture in a Picture), PoP (Picture outside a Picture) and split screen display
  • 2 x 2 Video Wall Processor
  • 4 x 1 Quad Screen Multiviewer function
  • Supports HDMI/DVI inputs / outputs
  • Various layouts controlled by software
  • High-bandwidth of 10.2 Gbps
  • Supports image-overlapping
  • Supports output scaling
  • Provisions PIP & POP
  • HDCP / EDID compliant
  • Able to zoom in on one input image three or four times per output
  • Supports output resolution change, contrast & brightness adjusting, H&V zooming and moving, and bezel adjustment


Video Input
Video Input Connector
Female DB 24+5
Video Input Level
T.M.D.S. 2.9V/3.3V
Video Input Impedance
Video Output
Video Output Connector
Female DB 24+5
Video Output Level
T.M.D.S. 2.9V/3.3V
Video Output Impedance
Video Signal
DVI (or T.M.D.S)
Switching Speed
200ns (Max.)
340 MHz (6.75Gbit/s)
Transport Delay
5nS (±1nS)
< -50dB@5MHz
Front Panel Buttons, RS-232, TCP/IP, USB
RS-232 Pin Configurations
2 = TX, 3 = RX, 5 = GND
Control Software
Power Supply Internal:
100VAC ~ 240VAC, 50/60Hz
-20 ~ +158 °F (-20 ~ +70 °C)
18AWG Power Cord
NEMA 5-15P to IEC-320-C13
10% ~ 90%
Power Consumption
Dimension (WxHxD)
19 x 1.75 x 9.25 in (483 x 44 x 235mm)
Product Weight
11.5 lbs (5.2Kg)
