8x8 Cat5e/6/7 HDMI Matrix Switch 4K x 2K with HDBaseT over Single Cat5e/6/7 cable includes 8 HDBaseT Receivers


#AB-5688LCM-CT-4K
$9000.00 $5099.00


Description :

8x8 HDBaseT HDMI Matrix Switch with 4KX2K Support

KVMSwitchTech's AB-5688LCM-CT-4K is a professional 8x8 HDMI Matrix Switcher with 4K x 2K support. This unit has (8) HDMI Inputs and (8) HDMI and (8) HDBaseT™ Outputs. The AB-5688LCM-CT-4K is based on the HDBaseT™ standards and supports full HDMI video resolution with embedded EDID and PoH function (optional), Audio, RS-232, Ethernet and bi-directional IR, all over a single Cat5e/6/7 cable. With a signal bandwidth of 340Mhz, there is no signal degradation. High Definition Digital signals can be selected and distributed to any (8) Inputs to (16) outputs simultaneously (channel outputs mirrored). This 4K x 2K HDMI Matrix unit is certified as being fully CEC and HDCP 1.3 compliant, full HD 4K2K HDMI V1.4a, 3D formats. It Supports UXGA/WUXGA/DVI 1920x1200 resolutions to any HD display. The AB-5688LCM-CT-4K has 8x HDMI Inputs, effectively making this an (8) In by (16) Out switcher (same signal on both HDMI and HDBaseT™ outputs ). Using the IR remote the switcher’s HDBaseT™ Extender Transmitter (Tx) allows you to connect a source in a remote location. Likewise, the HDBaseT™ Output and our HDBaseT™ Receiver allows you to connect a display in a remote location. The EDID management can be selected between (8) different modes. Control is provided via front panel push buttons, IR remote, RS232 or TCP/IP (not a web-browser). A RS232 Windows GUI interface is provided for matrix routing control (Windows only).

This 8x8 Cat5e/6/7 HDMI Matrix Switch 4K x 2K with HDBaseT over Single Cat5e/6/7 cable includes 8 HDBaseT Receivers.


Product Features



  • (8)x HDMI digital video and digital multi-channel audio player source devices matrix switched to (8)x HDMI outputs and (8)x HDBaseT™ transmitter with optional PoH (via the AB-5688CAP) outputs to (8)x destinations
  • Application HDBaseT™ specification with optional PoH (via the AB-5688CAP), IR, RS-232, multi-channel digital audio format and HD video signals over single CATx (6/6a/7) category cable
  • HDMI digital video w/ embedded HDCP, DVI format and CEC/HDCP 2.0 compliant
  • Worldwide control EDID modes for HDMI full 4K2K (24/30Hz) HD video resolutions
  • Link speeds of up to 6.75Gbps (link clock rate of 340MbHz). Supports HDMI 4K2K, 1.4a 3D formats
  • Wide range of HD resolutions from PC XGA to WUXGA 1920x1200 and HDTV/DTV HDMI resolutions 480i/480p, 576i/576p, 720p, 1080i/p & 4K2K (24/30Hz)
  • Compatible with all HDMI source devices, PC monitors, Plasma HD displays, HDTV and audio receivers or audio amplifiers
  • Digital video TMDS formats resolutions up to 4K2K with Deep color 36-bit
  • Digital audio supports: Dolby TrueHD, Dolby Digital, Dolby Digital Plug/ex, DTS, DTS-HD, DTS-HD Master, DTS-EX PCM, PCM2, LPCM2
  • Audio inputs supports: HDMI multi-channel digital audio
  • Audio outputs supports: HDMI multi-channel digital audio
  • Various User Interface Control:
    • Windows based GUI control via RS232 port
    • Front panel push button
    • IR wireless remote control
    • Ethernet switcher control
    • Third party RS-232 controller (via simple ASCII)
  • Supports world wide control functions: Full function front panel controls: ALL/OFF/RECALL/ENTER/MEMORY/EDID/LOCK
  • Supports EDID modes: Embedded EDID modes: FSS/H24-3D/H24-3D-M/H36-3D/H36-3D-M/DVI-D 1280x1024-60Hz/DVI-D 1920x1200-60Hz/AUTO
  • External modes: Learning mode
  • Automatic scanning input & output status via LCM show on front panel
  • Supports IR remote and IR extender with distances up to ~984 ft (300M) Maximum
  • EDID configuration via internal modes
  • Supports universal power adaptor AC90V~AC240V, 50/60Hz


Specifications

Type of HDMI Switcher
8x Inputs to 8x Outputs HDMI over HDBaseT™ Matrix Switch with Single CATx
HDMI Support
HDMI 4K2K, 1080p-@60Hz, H36-bit Deep color, 3D of HDMI V1.4 formats
HDBaseT™ Support
Bi-Directional IR, RS-232, Multi Format Audio, Ethernet and optional PoH (via the AB-5688CAP), over one CATx cable
HDCP/CEC Support
HDCP 2.0 Compliant, CEC Compliant
Video Bandwidth
Double Data Rates: 340Mhz, Total 6.75Gbps bandwidth
Digital Video Support
HD:480i/480p/720p/1080i/p and 4K2K up to 36bit deep color
Inputs
8x HDMI (HDMI or DVI digital source)
Video Outputs
  • HDMI: 8x HDMI (to Destination)
  • HDBaseT™: 8x HDBaseT™ Transmitter with optioanl PoH (via the AB-5688CAP) over a CATx cable & RJ-45 connector
HDBaseT™ Control Inputs
  • 8x IR in (Send IR signals to 8x Rooms via HDBaseT™ Transmitter)
  • 1x ALL IR in (Send IR Signals to 8x Rooms-Via HDBaseT™ Transmitter)
HDBaseT™ Control Outputs
  • 8x IR out (Link to Receive IR signals from 8x Rooms via HDBaseT Extender)
  • 1x ALL IR out (Link to Receive IR signals from 8x Rooms via HDBaseT™ Extender)
  • 1x All Tx LAN (All switcher HDBaseT™ Transmitter Ethernet link to HDBaseT™ Receiver)
HDBaseT™ Control I/O
8x RS-232 I/O (Control 8x Rooms RS-232 via switcher HDBaseT™ Extender Tx)
Switcher Controls
  • 1x Select & Function buttons on front panel (Data status via LCM panel show out)
  • 1x IR Remote Controller (switch control)
  • 8x IR Room Remote Controller (switch control)
  • 1x IR External port (switch control via 3.5mm OD Jack)
  • 1x RS-232 series interface (switch control)
  • 1x Ethernet series interface (switch control)
Source Status
Input status LEDs indicates presence of a live signal
(25) Function Control Key
1. ARC, 2. AUX, 3. ALL, 4. OFF, 5. RECALL, 6. ENTER, 7. MEMORY, 8. LOCK, 9. EDID, 10. Destination button 1 thru 8, 11. Source button 1 thru 8
(8) EDID management

Select Embedded EDID
  • Mode1: FSS
  • Mode2: H24-3D
  • Mode3: H24-3D-M
  • Mode4: H36-3D
  • Mode5: H36-3D-M
  • Mode6: 4K2K-3D, PCM-2CH
  • Mode7: DVI-D 1920x1200-60Hz
  • Mode8: AUTO
Select LEARNING Mode
Learning Destination EDID to Link Source
Infrared Frequency
38Khz
IR External Distance
~984 ft/300M maximum
HDBaseT™ Extender Distance
~328 ft/100M maximum
HDMI I/O Connector
HDMI Type A-SMD 19pin Female Type
Temperature
32°F-100°F Operation (0°C-38°C)
Dimensions (LxWxH)
19 x 9.85 x 3.5 in (482x250x88 mm)
Rack Mount
2RU High 19 in Rack Mount #2U-440L (with rack mount)
Power Supply
AC 100~240VAC 50/60Hz (Power Consumption: 10A Maximum)
Safety Approvals
CE, FCC, RoHS, REACH
Product Weight
3.75 Kg/6.25 lb
Shipping Weight
9.5 Kg/21 lb
