DVX-PLUS USB DVI Extender over Cat6 STP Cable up to 275ft

Name: DVX-PLUS USB DVI Extender over Cat6 STP Cable up to 275ft
Brand: KVMSwitchTech
SKU: DVX-PLUS
Price: 420.00 USD
Availability: InStock

$420.00 $600.00 -30%

In stock — ships fast

Description :

The DVX-PLUS, DVI USB Extender over shielded CAT6 Cable enables users to extend DVI Video signal and USB devices up to 275ft from the DVI source. The DVX-PLUS extender unit includes a transmitter and receiver set. The transmitter is placed next to your Computer and the receiver is placed next to your DVI Monitor and USB devices. The signal extension is over a two shielded twisted pair CAT6 cables.

Fast shipping
Genuine warranty
RMA support
Expert help

Product Features

Extends USB and DVI Signals up to 275ft from the computer
Easy to install, extension over STP cable
Data recovery for digital video
Supports 1920x1200 digital video resolution
Fully Compliant with USB 1.1 specifications
Supports 1.5 and 12 Mbps data rates
Compatible with all operating systems
External power adapter for transmitter and receiver unit
Fully transparent (does not use any emulation)
Plug and Play functionality

Specifications

Video Interface	DVI-D Single Link
Single Link Range	480P,720i/p, 1080i/p
Video Data Rate	1.65 Gbps
Resolution	1920 x 1200 @ 60 Hz, Resolution up to 1280 x 1024 min @ 75Hz
Power Supply	Universal Switch mode PSU (90-240V Input) 5VDC 1A
Input Interface	DVI-D
USB Data
USB Max Data Rate	12Mbps
USB Compatibility	1.0 and 1.1
Connector Type
Transmitter	Type A
Receiver	Type B
Dimensions (WxDXH)	5.5" x 1" x 3.5" inches
