MRK-F17b-3 Cyberview 2U 17" Triple Display VGA and DVI-D 1080p High Resolution 1920 x 1080 Rackmount Monitor Keyboard Console Drawer Trackball


#MRK-F17b-3
$6000.00 $5341.00

Description :

Austin Hughes Cyberview MRK-F17b-3 2U 17" Triple Display 1080p High Resolution 1920 x 1080 VGA and DVI-D Rackmount Monitor Keyboard Console Drawer is a combination of Keyboard, VGA and DVI-D Video and trackball Mouse (KVM) in 2U Rack drawer. This 1080p  Rackmount LCD Keyboard  comes with a combo interface cable which supports both USB and PS2 Keyboard interface. MRK-F17b-3 units are specifically designed for Command and Control Centers for side by side display applications.To ensure chassis ruggedness, mobility and quality, as well as being suitable for harsh environment applications, the MRK-F17b-3 console drawer is meticulously constructed by our team of experts in our own CNC facilities for such applications.




Product Features



  • Cyberview MRK-F17b-3 2U 17" widescreen LCD console drawer with VGA and DVI-D inputs per display
  • Rugged construction for mobility & durability
  • Fits 24" ~ 36" rack via adjustable mounting brackets
  • Five LED backlit display selections (WUXGA, FHD 60Hz, FHD 144Hz, 4:3 )
  • 104-key Keyboard with either touchpad or trackball
  • 2-Year standard warranty ( upgradable up to 5 years)
  • HDMI with Speakers (Optional)
  • 3G / HD / SD-SDI Broadcast-grade input (Optional)
  • Front USB hub port for device access (Optional)
  • 48V, 24V or 12VDC input (Optional)
  • Sunlight Readable LCD for 17" FHD & 19” 4:3 (Optional)

Specifications

LCD Panel
Size (diagonal)
17.3" TFT
Max resolution
1920 x 1080
Brightness (cd/m2)
300
Backlight
LED

Colors
16.7 M, 8-bit
Contrast ratio (typ)
1000 : 1
Viewing angle (L/R/U/D H/V)
89/89/89/89
Display area (mm)
381.888H x 214.812V
MTBF (hrs)
50,000
Signal input
VGA and DVI-D (HDMI Optional)
Environmental
Operating
0 to 55°C Degree
Storage
-20 to 60°C Degree
Relative humidity
5~90%, Non-condensing

Shock
10G acceleration (11 ms duration )
Vibration
10~300Hz 0.5G RMS random vibration
Operating Altitude / Non Operating Altitude
16,000ft  / 40,000ft
Power
Input
Auto-Sensing 100 to 240VAC, 50 / 60Hz
Consumption
Max. 38 Watt, Standby 5 Watt
Dimensions

Product
17.4 x 15.7 x 1.73 inch
Packing
23.4 x 24.5 x 5.5 inch
Weight

Net
56.5 lbs
Certifications
CE, FCC, RoHS2, Reach Compliant
