UHD 4K@30Hz 1x8 HDMI Extender Splitter upto 394 ft

( 50 Reviews )

$3000.00 $2160.00

Description :

The HDMI-CATSPU-8 combines the extender and splitter functions to split (1) HDMI signal to (8) identical HDMI signals via a network cable. This UHD 4K@30Hz 1x8 HDMI extender, HDMI-CATSPU-8 works with (8) receivers to transmit the HDMI signals up to ~394 ft/120M. The IR signal transmission controls the source device operation for long distances and it is widely applied in HD audio visual display rooms, exhibition centers and digital monitoring systems.

This unit comes wth eight receivers.

Add to Cart

Product Features

Supports (1) HDMI Input to (8) HDbitT outputs
Up to ~394 ft/120M transmission distance over a single CAT6 cable (high quality cable can reach ~492 ft/150M)
Compatible with a receiver devices which support HDbitT transport protocol
HDCP Compatible

Specifications

HDMI Signal	Compatible with HDCP
Transport Protocol	HDbitT
Supported Resolutions	480i@60Hz, 480p@60Hz, 576i@50Hz, 576p@50Hz, 720p@50/60Hz, 1080i@50/60Hz, 1080p@50/60Hz 4K2K@24/25/30Hz
Transmit Distance	Up to ~394 ft/120M transmission distance for 4K2K@24/25/30Hz ultra HD over a single CAT6 cable
IR Signal	Supports 20~60KHz IR devices
Input	(1) HDMI
Output	(8) RJ45
Working Temperature	32°F-140°F (0°C-60°C)
Power Supply	DC5V/2A
Power Consumption	<10W
Dimensions (WxDxH)	11.3 x 3.9 x 1.75 in (288x98x44.4mm)
Weight	2.2 lb/1000g
Color	Black

View User Manual
