16x8 Cat5e/6 HDMI Matrix Switch with HDBaseT over Single Cat5e/6 STP cable and TCP/IP Control includes 8 HDBaseT Receivers

( 122 Reviews )

$18000.00 $10500.00

Description :

16x8 HDBaseT HDMI Video Matrix Switch with 4KX2K Support

KVMSwitchTech's HDB-HDMI-1608-IP is High-performance 16x8 Cat6 HDMI Matrix Switcher over HDBaseT with 16 HDMI inputs and supports simultaneously 8 CAT6 STP outputs. This 16x8 Cat6 HDMI Matrix is based on HDBaseT technology and supports HDMI Video with embedded audio, RS-232, IR bi-directional, and TCP/IP all over a single Cat6 STP cable. One Cat RJ45 Connection for each Output extends the HDMI Signal to remote location via HDBaseT HDMI Receivers (Cat6 STP Cable 230 Feet (70 meters).

Add to Cart

Product Features

Flexible universal slots for HDMI inputs and HDMI over cat5 outputs
Front panel LCD- for operation and working status
Hot Swappable with easy plug n play
Cross switching - any input to any output
Backlit button provides label which is change-able for customizing
RS232 Serial control port, using serial commands
TCP/IP Control via Ethernet
Front Panel security lock prevents unauthorized use when the matrix is installed in an unsecured environment
9 Global presets- to save and recall the function
3U Rack-Mountable aluminum enclosure
Dual-Internal international power supply (100Volt~240Volt AC, 50/60Hz) for worldwide compatibility
Backed by 3-year full parts & labor warranty

Specifications

Chassis Input	16 x Inputs (HDMI)
Chassis Output	8 x Outputs (Cat6 STP for HDMI upto 230 ft)
Bandwidth for each input/output	340 MHz (10.2 Gbps)
Input/ output impedance	75 ohms
Switching speed	200ns (max)
Gain	0 dB
Maximum delay	5nS (+/- 1nS)
Maximum pixel clock	165 MHz
Control
Serial control port	RS-232, 9-Pin female D connector
Pin Configurations	2 = TX, 3 = RX, 5 = GND
Installation	Rack Mountable
Front panel control	Buttons
Options	TCP/IP (Ethernet Controller)
General
Frame Size	3U Rack Chassis
Dual Internal Power Supply	110VAC ~ 240VAC, 50/60Hz
Humidity	10% ~ 90%
Temperature	-20 ~ +70 C
Power Consumption	50W
Case Dimension	W483 x H175 x D320mm
Product Weight	6.5 Kg

View User Manual
