W119-S801e Cyberview 1U 19" Widescreen Rackmount Monitor Keyboard Drawer with integrated 8 Port USB KVM Switch Touchpad

( 119 Reviews )

$1800.00 $1589.00

Description :

W119-S801e Cyberview, 1U 19" WideScreen Rackmount LCD keyboard with integrated 8 port USB KVM Switch is a combination of Keyboard, Video and touchpad or trackball mouse (KVM) in 1U drawer. This widescreen Rackmount Monitor drawer is a cost effective solution and saves space for rack environments. These Wide screen format Rack LCD units are used for a wide range of government, military, surveillance and commercial applications. Please note cables must be purchased separately.

Add to Cart

Product Features

Widescreen Rackmount Monitor with 8 Port USB KVM Switch
Cost efficient Combo KVM integration
19" Widescreen LCD with high resolution 1440x900
Mix PS/2 ,USB & SUN with Multi-Platform Switch capability
1U Rackmount drawer with 19" Widescreen LCD
Combo interface either PS/2 or USB input to the LCD drawer
Multiple keyboard language selections with either touchpad or trackball
Enhanced aesthetics with new molded front panel and two point lock

Specifications

LCD	19" Wide Screen Samsung LCD
Environmental
Operation	0° to 50°C Degree
Storage	-5° to 60 °C Degree
Relative Humidity	5~90%, non-condensing
Shock	10G acceleration (11ms duration)
Vibration	5~500Hz 1G RMS random vibration
Max Resolution	1440 x 900
Brightness (cd/m²)	300
Color Support	16.7 M
Contrast Ratio(Typ.)	1000:1
Viewing Angle (H/V)	160° x 160°
Display Area (mm	408 x 255
Tr Response Time (ms)	1.3
LCD Panel MTBF (hrs)	50,000
Resolution	720 x 400, 70 Hz ; 640 x 480, 60/ 70/ 72/ 75 Hz; 800 x 600, 60/ 70/ 72/ 75 Hz; 1024 x 768, 60/ 70/ 75 Hz; 1152 x 864, 60/ 70/ 75 Hz; 1280 x 720, 60/ 70/ 75 Hz ; 1280 x 1024, 60/ 70/ 75 Hz; 1440 x 900, 60 Hz
Plug & Play DDC	EDID 1.3
Console Port (Combo)	DB-15 connector for VGA / Keyboard / Mouse ( Combo PS2 or USB)
Power Input	Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption	Max. 48 Watt, Standby 5 Watt
Regulation Approval	FCC, CE, UL
Dimensions
Product (WXDXH)	17.4 x 22.8 x 1.75 inches
Packaging (WXDXH)	23.6 x 30.3 x 7.1 inches
Weight
Net	44lbs
Gross	57lbs

View User Manual
