W119-1601b Cyberview 1U 19" Widescreen Rackmount Monitor Keyboard Drawer with integrated 16 Port PS2 KVM Switch Trackball

$2400.00 $1823.00

Description :

W119-1601b Cyberview, 1U 19" Widescreen Rackmount LCD Keyboard with integrated 16 port PS2 KVM Switch is a combination of keyboard, video, touchpad or trackball mouse (KVM) and KVM Switch in 1U drawer. This Wide Screen Rackmount Monitor drawer with KVM is a cost effective solution and saves space for Rack environments. These wide screen format rack LCD KVM Switch units are used for a wide range of government, military, surveillance and commercial applications.

Item Number: #W119-1601b

Product Features


  • 1U 19” Widescreen Rackmount LCD Keyboard combo with KVM Switch
  • PS2 input interface with KVM cable
  • Multiple Keyboard language selections
  • Enhanced aesthetics with new molded front panel and two point lock
  • Touchpad or trackball Keyboard option
  • PS2 /VGA input interface with KVM cables (CABLES NOT INCLUDED)
  • 19" Widescreen Rackmount LCD with resolution up to 1440 x 900

Widescreen Rackmount LCD Keyboard with KVM Switch

  • Cascade KVM Switches to control up to 128 Servers
  • High Video Quality - Up To 1440x900
  • Built-in microprocessor emulation for each port boots up process
  • Name servers up to 16 characters long
  • Scan Mode – Monitor servers at intervals 5 to 99 seconds
  • Password protection
  • Multi-platform support enables users to mix PCs, SUN Microsystems, IBMs, HPs, Compaq and Dell Servers


Integrated KVM Switch Options

  • PS2 KVM Switch, USB KVM Switch, Cat5e/Cat6 KVM Switch, IP KVM Switch and Matrix KVM Switch
  • Mix DVI-USB, VGA-USB, VGA-PS2 Servers
  • Rackmount LCD Keyboard with integrated KVM Switch offers Multi-Platform switching capability
  • Cost efficient Combo KVM integration
  • Secure remote user access (KVM Switch with TCP/IP Functionality)


19" Wide Screen Samsung LCD
0° to 50°C Degree
-5° to 60 °C Degree
Relative Humidity
5~90%, Non-condensing
10G acceleration (11ms duration)
5~500Hz 1G RMS random vibration
Max Resolution
1440 x 900
Brightness (cd/m²)
Color Support
16.7 M
Contrast Ratio(Typ.)
Viewing Angle (H/V)
160° x 160°
Display Area (mm
408 x 255
Tr Response Time (ms)
LCD Panel MTBF (hrs)
720 x 400, 70 Hz ; 640 x 480, 60/ 70/ 72/ 75 Hz; 800 x 600, 60/ 70/ 72/ 75 Hz; 1024 x 768, 60/ 70/ 75 Hz; 1152 x 864, 60/ 70/ 75 Hz;

1280 x 720, 60/ 70/ 75 Hz ; 1280 x 1024, 60/ 70/ 75 Hz; 1440 x 900, 60 Hz
Plug & Play DDC
EDID 1.3
Console Port (Combo)
DB-15 connector for VGA / keyboard / mouse ( Combo PS2 or USB)
Power Input
Auto-sensing 100 to 240VAC, 50 / 60Hz
Power Consumption
Max. 48 Watt, Standby 5 Watt
Regulation Approval
Product (WXDXH)
17.4 x 22.8 x 1.75 inches
Packaging (WXDXH)
23.6 x 30.3 x 7.1 inches
